0.5mm Pitch FPC Right Angle Header Connector SMT UP Contact With Lock SGS H=1.2

0.5mm Pitch FPC Right Angle Header Connector SMT UP Contact With Lock SGS H=1.2

0.5mm Pitch FPC Right Angle Header Connector SMT UP Contact With Lock SGS H=1.2
0.5mm Pitch FPC Right Angle Header Connector SMT UP Contact With Lock SGS H=1.2
Categories WCON Connector
Brand Name: WCON
Model Number: 5142-XXRZUWWR01
Certification: SGS/ROHS
Place of Origin: China
MOQ: 1000pcs
Price: negotiation
Payment Terms: T/T
Supply Ability: 800000pcs
Delivery Time: 15~25Day
Packaging Details: Reel packing
port: hong kong
pitch: 0.5mm
plastic high: H=1.2
Factory address: Dong Guan Guang Dong
Contact Resistance:: 20mΩ Max
Operation Temperature:: -25℃ to +85℃
Contact Now
Company Info.
WCON ELECTRONICS ( GUANGDONG) CO., LTD
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

0.5mm Pitch FPC Right Angle Header Connector SMT UP Contact With Lock SGS H=1.2

0.5mm Pitch FPC WCON Connector Right Angle SMT UP Contact With Lock SGS H=1.2

Current Rating0.4AMP
Contact Resistance:20mΩ Max
Insulation Resistance:500MΩ Min
Withstand Voltage:200AC/DC
Operation Temperature﹣25℃ to +85℃
TerminalPhosphor Bronze Tin-Plated
Fitting NailBrass Tin-Plated
Insulator Material:Thermoplastic (UL94V-0)
Standard:LCP+30%GF


1.27mm Pcb Female Header / 20 Pin Header Connector 180ƒÆ’†™ƒ ¢‚¬„¢ƒÆ’¢‚¬ ƒ¢¢š¬¢ž¢ƒÆ’†™ƒš‚¢ƒÆ’‚¢ƒ¢¢š¬…¡ƒš‚¬ƒÆ’¢‚¬¦ƒš‚¡ƒÆ’†™ƒ ¢‚¬„¢ƒÆ’‚¢ƒ¢¢‚¬Å¡‚¬ƒ¦‚¡ƒÆ’†™ƒ¢¢š¬…¡ƒÆ’¢‚¬Å¡ƒš‚°DIP PPS 30ƒÆ’†™ƒ ¢‚¬„¢ƒÆ’¢‚¬ ƒ¢¢š¬¢ž¢ƒÆ’†™ƒ¢¢š¬…¡ƒÆ’¢‚¬Å¡ƒš‚¯ƒÆ’†™ƒ ¢‚¬„¢ƒÆ’‚¢ƒ¢¢‚¬Å¡‚¬ƒ¦‚¡ƒÆ’†™ƒ¢¢š¬…¡ƒÆ’¢‚¬Å¡ƒš‚¼ƒÆ’†™ƒ ¢‚¬„¢ƒÆ’¢‚¬Å¡ƒš‚¢ƒÆ’†™ƒš‚¢ƒÆ’‚¢ƒ¢¢‚¬Å¡‚¬ƒ¦‚¡ƒÆ’¢‚¬Å¡ƒš‚¬ƒÆ’†™ƒ¢¢š¬…¡ƒÆ’¢‚¬Å¡ƒš‚¦GF UL94V-0Drawing:0.5 FPC 5142-XXRZUWXX0X.pdf


Item name: FPC connector
Product features: the use of a wide range of use of the front lock structure of high density, small size, light weight, good flexibility
Product material: LCP/PBT/PA6T
Scope of application: the product is mainly used in a variety of digital communication products, portable electronic products, computer peripheral equipment, instrumentation, automotive electronics and other fields. Such as mobile phone, digital camera, notebook computer, MID, MP345, handheld game consoles, sound system etc.
