Air Knife System Brewery Production Line Linear Structure Air Dryer Machine

Features

The air come into the high pressure air pipe through a filter into the air knife and form the belt of strong wind at the incision. Use the strong wind to dry the drops and the film on the sidewall from different directions. The equipment is mainly used for the pharmaceutical, health drinks, and the like automatic packaging production line for drying the surface of the glass bottle.

Main technical parameters

Capacity:2000-3000 bph

The bottle size: Bottle diameter:≤Φ100 mm

Bottle height:≤320mm

Power source: AC 380V 50HZ

Blower power :3×4Kw

Numbers of air knives :32 units

Outer size :800×2400×1700mm

The main structure and features

The equipment is the linear structure, mainly made up of frame, air knife system , fan components, piping, electrical system components and so on.

Features:

The device adopts the leading international advanced air knife technology with stable performance, high visibility, high drying effect, suitable for medium and high-speed production line: the air knife can rotate up and down ,right and left adjusting to dry areas and output level can be adjusted according to the size of air flow and the production capacity with simple operation .The device can apply for different type of bottles with no dust pollution caused by brush, maintenance-free, easy to clean the water from the bottles and porcelain bottles using is with the excellent special effects.

Electric system

Fan coil control: It is with high-pressure, using 380V, 50Hz AC power supply and fans take turn to open, in order to reduce the impact on power

Installation

The device through the connecting plate connects with the transmission line

Adjust the air knife hanger according to the bottle so that make the air knife at a reasonable position, and adjust the size of the wind gap and the wind volume of the wind to blow-dry the drops and water film on the sidewall.
