| Categories | Patterned Sapphire Substrates |
|---|---|
| Brand Name: | GaNova |
| Certification: | UKAS/ISO9001:2015 |
| Place of Origin: | Suzhou China |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Packaging Details: | Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers. |
| Model Number: | JDCD09-001-001 |
| Flat edge width: | 16±1.0mm |
| Flat edge angle: | A-plane±0.2˚ |
| TTV: | ≤5μm |
| BOW: | ≤-8~0μm |
| Front Surface Roughness: | ≤0.25nm |
| Back Surface Roughness: | 0.8~1.2μm |
50.80±0.10mm Patterned Sapphire Substrates 430±10μm A-Plane±0.2o
2inch Patterned Sapphire Substrates,LED Chip,Substrate Material
With the breakthrough of the patterned-sapphire substrate technique, the efficacy of high-brightness GaN-based LEDs has been driven to a record high of 150 lm/W. The efficacy enhancement of GaN-based LEDs with the patterned-sapphire substrate technique is generally attributed to the improvement in both light extraction efficiency and internal quantum efficiency.
| 2inch Patterned sapphire substrate | ||
| Item | Al2O3 |
|
| Dimension | 50.80±0.10mm | |
| Thickness | 430±10μm | |
| Flat edge width | 16±1.0mm | |
| Flat edge angle | A-plane±0.2o | |
| TTV | ≤5μm | |
| BOW | ≤-8~0μm | |
| Front Surface Roughness | ≤0.25nm | |
| Back Surface Roughness | 0.8~1.2μm | |
| Edge | Round | |
| Laser making | back | |
About Us
We specialize in processing a variety of materials into wafers, substrates and customized optical glass parts.components widely used in electronics, optics, opto electronics and many other fields. We also have been working closely with many domestic and oversea universities, research institutions and companies, provide customized products and services for their R&D projects. It's our vision to maintaining a good relationship of cooperation with our all customers by our good reputations.
FAQ
Q: Are you trading company or manufacturer ?
We are factory.
Q: How long is your delivery time?
Generally it is 3-5 days if the goods are in stock.
or it is 7-10 days if the goods are not in stock, it is according
to quantity.
Q: Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but do not pay the
cost of freight.
Q: What is your terms of payment ?
Payment <=5000USD, 100% in advance.
Paymen >=5000USD, 80% T/T in advance , balance before shippment.
|
