Single Sided Flex Rigid Printed Circuit Board PCB Manufacturer FR4 Rogers CEM-1

Post-Soldering Processing Supports Assembly SMT Patch Plug-In Processing

Single-Sided pcb

SMT basic process elements include: screen printing (or dispensing), mounting (curing), reflow soldering, cleaning, testing, repair

1. Screen printing: Its function is to leak solder paste or patch glue onto the PCB pad to prepare for the welding of components. The equipment used is screen printing machine (screen printing machine), located at the front end of the SMT line.

2, dispensing: it is to drop the glue to the fixed position of the PCB board, its main role is to fix the components to the PCB board. The equipment used is the dispensing machine, which is located at the front end of the SMT production line or behind the testing equipment.

3. Mounting: Its function is to accurately install the surface assembly components to the fixed position of PCB. The equipment used is the SMT machine, which is located behind the screen printing machine in the SMT production line.

4, curing: its role is to melt the patch glue, so that the surface assembly components and PCB board firmly bonded together. The equipment used is the curing furnace, which is located behind the SMT machine in the SMT line.

PCB assembly manufacturing service:

1. Turnkey contract PCBA( PCB assembly ) manufacturing

2. Strong ability in material sourcing and quality management

3. Quality authentication: Rosh(lead-free, Pb-free), ISO9001: 2008, UL

4. SMT, DIP and wave solder processing

5. Reliable OEM/ODM PCBA( PCB assembly ) service

6. Flexible & rigid PCB assembly manufacturing, PCB layout design

7. 4 layers. 6 layers ,multilayers PCBA( PCB assembly )

8. In-circuit testing, functional testing and flying probe testing

9. SMT placement for SOP, QFP, CSP, and BGA packages

10. Full experienced QC and inspector

11. PCBA( PCB assembly ) for power, communication equipment, remote control system and consumer electronic products and so on

Our Advantages:

1. Program and functional test and package by Free.

2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.

3. Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 21 years experience.

4. Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001, ISO14001,IATF16949

The company's products now mainly include: smart home, hotel intelligent switch control, advertising machine motherboard, industrial control matrix, communication equipment board, code scanning gun, ear temperature gun and other semi-finished products, finished products, experience 8 years, product quality and after-sales service has been praised by customers.

Why did you choose us?

1,Experienced

Focused on PCBA electronic manufacturing for 8 years

Best Partner for Listed Companies

Serving over 60 European and American enterprises

Helping clients solve design issues over 500 times

Helped customers solve MP issues over 800 times.

Helping customers improve testing reliability over 1000 times

2,Quality control

ISO9001: 2015

ISO13485

IATF16949

MES

Traceability system

Fully automatic FCT testing

3,Quick response

Quick response principle within 1 hour

7 days * 24 hours

Team responsibility system

Sales personnel with a bachelor's degree or above
