Custom Industrial Touch Screen Display Module 24 Inch With EETI ILITEK Glass Sensor

Categories Touch Screen Display Module
Place of Origin: Guangdong, China
Packaging Details: Inner packaging: packing with bubble bags and filling with foam plastic materials;
Outer packaging: packing with serial size of carton or wooden box.

24 inch digitizer transfer capacitive touch screen overlay
Supply Ability: 1000000 Piece/Pieces per Month
MOQ: 2 sets
Price: $176.00/sets 2-499 sets
Brand Name: EG
Certification: CE/FCC/ROHS/ISO9001/ISO14001
Type: TFT
Product name: 24 inch Touch Screen Display Module
Products Status: Stock
Size: 24''
Aspect Ratio: 16:9
Panel Type: TFT-LCD
IC controller: EETI
Brightness: 500 cd/m
AA (SG/mm): 532.36*299.89 ± 0.2mm
Points: 2-10 Touch Points
Port: Guangzhou port/ Shenzhen port,China
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Custom Industrial Touch Screen Display Module 24 Inch With EETI ILITEK Glass Sensor

Industrial Large Custom 24 Inch USB Port Touch Screen Display Module With EETI ILITEK Glass Sensor


Touch Panel P/NEG-24-A-1609V1
Display P/NG24HAN01.1
Screen Diagonal24/16:9 inch
Cover Outline Dimension567.44*336.86 mm
Touch Panel View Area527.44*296.86 mm
Touch Panel Active Area532.36*299.89 mm
Display Outline Dimension543*317.4 mm
Display Active Area531.04*298.46 mm
Total Thickness16.04mm
View angle89/89/89/89, Full view angle
Cover surface hardness≥6 H
Impact resistance≥IK07
Luminance, white500cd/m2
Operation Conditions20%~90% RH
Storage Conditions20%~70% RH
Touch Response Time≤25 ms
Pixels H×V1920(X3)*1080
Pixel Pitch274.5 (per one triad) ×274.5 um





Shape:Standard/CustomizationMaterial:Glass,FilmOptical Bonding
Color:Silkprinting,logoFPC:Shape Design OptionalAir Bonding
Glass material:Glass,PMMAIC:EETI/ILITEKLCD:LED,OLED,TFT,IPS
Treatment:AR/AF/AG/Anti-UVInterface:12C/USB/RS232
Thickness:1.1-12mm






  • How can we guarantee quality?

    All products must pass 5 times QC inspection with 100% appearance& Function test on each piece.
  • Which operating systems does is support?

    Our products support Windows,Android,Mac,Linux and Chrome.
  • What are the advantages of our products?

    High precision,response quickly,good quality control,excellent after-service.
  • What is included in your products?

    Touch panel+LCD display+Air bonding/Optical bonding+Controller board+USB Cable.(AD borad and display cables are optional)
  • Do you support sample testing?

    Yes,We can provide standard model in stock or customized sample in 3-7 days for testing purpose.
