| Categories | Concrete Mixer Truck |
|---|---|
| Brand Name: | HOWO mixer truck |
| Model Number: | ZZ5317GJBS3267W mixer truck |
| Certification: | ISO CCC |
| Place of Origin: | China |
| MOQ: | 1 Unit |
| Price: | $30,000 |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 units per week |
| Delivery Time: | 20 days |
| Packaging Details: | Bulk or RORO Ship |
| Length*Width*Height(mm): | 10920*2500*3999 |
| Capacity(m3): | 16 |
| Loading mass(kg): | 12840 |
| Air conditioner: | With safety belts for driver and co-driver;With air conditioner |
| Warning system: | Each side and rear with reflecting mark |
| Tyre: | 11.00-20,11.00R20,12.00-20,12.00R20 |
| Company Info. |
| Jinan Heavy Truck Import & Export Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
16cbm 8x4 Sinotruk HOWO Concrete Mixer Truck 20-60 ton CCC Passed
Specifications:
howo 8x4 mixer truck
380HP,Euro III
SINOTRUK ten speed gear-box
10920*2500*3999
Capacity(m3) 10
Engineering vehicles mixer truck HOWO 8X4
TECH PARAMETERS
| Type | Concrete Mixer Truck | ||||
| Model | TAG5310GJB | Blade thickness(mm) | 4 | ||
|
| Tank thickness(mm) | 5mm(T520JJ Material) | ||
| Head thickness(mm) | 6 | ||||
| Front overhang(mm) | 1500 | ||||
| Capacity(m3) | 16 | Rear overhang(mm) | 2670 | ||
| Loading mass(kg) | 12840 | Approach/departure angle(°) | 16/14.2 | ||
| Curb weight(kg) | 18030 | Wheelbase(mm) | 1800/3600/1350 | ||
| Model | WD615.96C | Trace(F/R) (mm) | ||
| Power(kw) | 276 | Axle number | 4 | ||
| Cylinder number | 6 | ||||
| Rated speed(rpm) | 2200 | ||||
| Displacement(ml) | 9726 | Steel Plate spring (pics) | Front | 9 | |
| Torque(N.m) | 1500 | Rear | 12 | ||
| Tire Model | 11.00-20,11.00R20/ | Tire number | 12 | ||
| Warning system | Each side and rear with reflecting mark | Ground clearance(mm) | 520 | ||
|
