1528.77-1563.86nm 10G SFP+ DWDM , 80km LC SFP DDMI Optical Transceiver

1. Features:

Supports 9.95 to 11.3Gb/s bit rates

Hot-Pluggable

Duplex LC connector

100GHz ITU Grid, C Band

DWDM EML transmitter, APD photo-detector

SMF links up to 80km

2wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface

Power Supply :+3.3V

Power consumption<1.5W

Temperature Range: 0~ 70°C

RoHS compliant

2. Applications:

10GBASE-ZR/ZW Ethernet

Sonet OC-192/SDH

10G Fibre channel

DWDM Networks

3. Description:

Moduleland's TSPLXG80D-Dxx is a very compact 10Gb/s optical transceiver module for serial optical communication applications at 10Gb/s. The TSPLXG80D-Dxx converts a 10Gb/s serial electrical data stream to 10Gb/s optical output signal and a 10Gb/s optical input signal to 10Gb/s serial electrical data streams. The high speed 10Gb/s electrical interface is fully compliant with SFI specification.

The high performance DWDM EML transmitter and high sensitivity APD receiver provide superior performance for Ethernet applications at up to 80km links.

4. Optical Parameters(TOP = 0 to 70°C, VCC = 3.135 to 3.465 Volts)

6. About us

Moduleland locating in Hanoi Vietnam, is a factory based manufacturer of optical transceivers covering various types widely applied to WAN, LAN, SAN, Fiber Channel, FTTX, etc.

1. Warranty

Five years Warranty, three monthes free exchange and one year free repairing.

2. OEM, ODM are welcome.

3. Free sample will be provided.

Free samples under a certain value are available,with freight cost collect.

4. Any Inquire is welcome.

Any inquire will be replied within 24 hours.

5. After-sales service.
a. From the beginning of production till the successful delivery, we will track on time and post you the status.
b. When the goods arrived, if you have question after inspection, please feel free to contact us, we'll provide solution.

Q: What payment terms do you accept?

A: T/T,L/C at sight,Western Union are acceptable. Other payment terms are negotiable.

Q: what is the lead time?

A: For standard products,we keep enough stock,cqn ship out in 1-3 days after PO confirmation.For big quantity and special products,Please check lead time with our sales representative.

Q: What are the shipping ways can you offer?

A: For small quantity we ship by Express like DHL,FedEX,TNT,UPS, EMS etc. For large quantity we can use airshipment ot other appointed method by clients.

Q: What euipments can your products be compatible with?

A: Our products can be compatible with all market brand.

Q: How to place an order?

A: 1> Confirm order details with our sales representatives.
2> Proforma Invoice confirmed, the order will be arranged upon receipt of your payment.
3> Confirm shipping details and dispatch goods, tracking number will be sent to you promptly after the shipment is picked up.
4> We will help to track your goods until you receive them safely.
