20" 8 Cartridges 200 Micron Filter Housing With Flange

Categories Cartridge Filter Housing
Brand Name: Dagyee
Model Number: DYG-8F-20''
Certification: CE
Place of Origin: Jiangsu.China
MOQ: 1PCS
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200SET
Delivery Time: 15 work days
Packaging Details: Wooden box, standard container, Customers can specify requirements
Condition: New
Product name: Cartridge Water Filter Housing
Material: SUS304, SUS316
Warranty: 1 Year
Dimensions: 300*850
Face treatment: Petroleum
Length: 20''
Applicable field: Petroleum
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

20" 8 Cartridges 200 Micron Filter Housing With Flange

Dagyee DYG-8F-20'' Micron Precision 8 Cartridges Filter Housings 20''Specification With Flange



DAGYEE Cartridge Housing


Cartridge filter, also known as security filter. The shell is made of high quality stainless steel, filter using molded filter, The liquid went through filter under pressure, residue left on the filter, and the filtrate outflow through the filter can effectively remove impurities in the water, sediment and suspended solids, bacteria. Molded filters are: cloth, screen, filter, sintered filter tube, wound filter, melt-blown filter, micro-porous filter and multi-function filter. Due to different filter, the filter pore size is not the same. Precision filter is between the sand filter (coarse) and a filter between ultra-filtration, filter pore size generally between 0.01-120um.For the same form of filter,it is divided into different models by their dimensions.


8 Cartridges Filter Housings 20''Specification With Flange


ModelDYG-8F-20''
MaterialSUS304 SUS316
Applicable Filter CartridgesIndustrial PP;String Wound;304;316
Filtration accuracy0.1-200UM
Connection TypeWith a clamp /BSP female
Surface treatmentMirror reflection
Housing Dimensions (mm)Ø300*850
Max. Flow Rate (m3 /h)10
Max. Operating Conditions (bar/°C)10/150
Inlet/Outlet (Quick Connector)38
Length of Filter Cartridge20''
No. of Filter Cartridges8
Max. Cartridge Outside Diameter(mm)Ø65


DAGYEE Cartridge Housing Feature

  • Adopt to mechanical polishing,material liquid touch area Ra<0.4um,absolute health level of polishing , can select all series electrolytic polishing.
  • It can increase the vent hole and dreain hole diameter Effectively , and can connect 8mm pipe.
  • Drain valve independent from the exhaust valve thread joint sets and pagoda,operating is more convenient.
  • Adopt to hing segmented clamp ,20% higher than an ordinary card hoop pressure,maximum pressure up to 1.0Mpa.
  • Supporting feet adopt to strengthening threaded,not easy sliding teeth;Install a adjustable nut at the bottom of the leg , filter's height can be adjustment .

DAGYEE Cartridge Housing Application

  • Water Treatment, RO system;
  • Pharmaceuticals, API, Biologics;
  • Food and Beverage, Wine, Beer, Mineral Water, Distillation Equipment;
  • Paints, Inks Plating Solutions;
  • Process Chemicals and Electronics Industry ;

DAGYEE Cartridge Housing Removal

  • Suspended matter
  • Algae
  • Impurities
  • Fine particles
