20 30 50 80 100 Mesh Molybdenum Wire Mesh/Heat Resistant Molybdenum Wire Mesh/99.95% Molybdenum Wire Mesh Cloth

20 30 50 80 100 mesh molybdenum wire mesh/heat resistant molybdenum wire mesh/99.95% Molybdenum Wire Mesh Cloth

Specification of Molybdenum Wire Mesh

Type: black molybdnum mesh and bright molybdnum mesh

Wire Diameter: 0.06mm--2.5mm

Aperture Size:0.025mm- 2mm

Mesh: 5-400 mesh

Woven Pattern: plain weave & twill weave

Width:1meter or as alients request

Molybdenum wire cloth features:

• High strength;
• High temperature resistance;
• Good electricity-conductivity;
• Resist to corrosion, wear, acid and alkali;
• High density.

Mesh	Wire Diameter	Mesh	Wire Diameter	Mesh	Wire Diameter
3	1.0mm	24	0.19mm-0.5mm	90	0.1mm-0.12mm
4	0.7mm-1.5mm	26	0.19mm-0.4mm	100	0.07mm-0.14mm
5	0.6mm-1.2mm	28	0.19mm-0.35mm	110	0.08mm-0.09mm
6	0.5mm-1.0mm	30	0.15mm-0.4mm	120	0.07mm-0.1mm
7	0.5mm-0.8mm	32	0.17mm-0.3mm	140	0.06mm-0.07mm
8	0.4mm-1.0mm	34	0.23mm	150	0.06mm-0.07mm
10	0.3mm-1.0mm	35	0.25mm-0.3mm	160	0.06mm
12	0.3mm-0.8mm	36	0.15mm-0.28mm	180	0.05mm
14	0.27mm-0.7mm	40	0.12mm-0.27mm	200	0.05mm-0.06mm
16	0.25mm-0.7mm	50	0.13mm-0.25mm	300	0.03mm-0.04mm
18	0.20mm-0.55mm	60	0.1mm-0.19mm	400	0.023mm-0.03mm
20	0.19mm-0.55mm	70	0.1mm-0.15mm	500	0.025mm
22	0.21mm-0.5mm	80	0.08mm-0.17mm	635	0.018mm

Molybdenum wire cloth applications:

• Used for heating elements in high temperature furnace;
• Filter chemical materials, food particles;
• Used in aerospace, nuclear power filed, oil and gas industry, electric-vacuum industry.

Molybdenum Chemical Composition (%):

C	Fe	Ni	O	Si	N	Mo
0.01	0.01	0.005	0.007	0.01	0.02	Rem

1. paper tube support inside + craft paper + wire mesh + craft paper + air bubble paper + paper tube + wooden box

2. Special packing can be customized

3. Wooden Pallet

1.How to make a inquiry of Molybdenum Mesh ?
You need to provide material,mesh number, wire diameter,size and the quantity to ask an offer, you can also indicate if you have any special requirement. We'll providea formal quotatiom list after your inquiry received.

2.Could you provide free sample ?
Yes, we can provide free sample in half A4 size together with our catalogue. But the courier charge will on your side. We'll send back the courier charge if you make an order.

3.How is your Payment Term ?
Generally, our payment term is T/T 30% in advance and the balance 70% against the copy of B/L. Other payment term we can also discuss.
