Categories | Waste Paper Hydraulic Baler |
---|---|
Brand Name: | NKBALER |
Model Number: | NK Series |
Certification: | CE,ISO |
Place of Origin: | Wuxi ,China |
MOQ: | 1 sets |
Price: | USD 2800-280000 |
Payment Terms: | TT/LC |
Supply Ability: | 200-300 SETS PER YEAR |
Delivery Time: | 10-30 days |
Packaging Details: | Wooden case |
PLC system: | Mitsubishi |
Bear: | NSK |
Seals: | America |
Cylinder: | China |
Motor: | Siemens |
Pump: | Taiwan ,China |
Steel: | Bao Steel |
Valve: | Shanghai ,china |
Hydraulic Part: | Japan brand in China |
Electrical components: | Schneider |
Tubing /pipe: | China |
Quality: | good |
Dimension: | 6000x2000x3000mm |
Tie Lines: | 4 or 5 lines |
Capacity: | 2-3 bales/hour |
Color: | Customized |
Hydraulic Power: | 160Ton |
Pressure: | 25 tons |
Baling Force: | 30-200 tons |
Strapping Method: | Four Strapping |
Machine Size: | 12T |
Control System: | PLC |
Packaging Material: | plastic bottles waste paper |
Coloer: | Bule |
Usage :
Specialized in recycling and compressing the loose materials like plastic films ,PET bottles, plastic pallets ,waste paper ,grass ,fiber ,used clothes ,cartons ,cardboards trims ,scrap ,etc .
Features
●Servo System With low Noise ,low consumption which is reduce half power of electrical charge,Smoothly running without any shake
●Fully automatic compress and baling, suitable for large amount material places, after baling it is easy store and reduce the transportation cost.
● Photoelectric switch activates baler when charge box is full
● Unique automatic strapping device, speed quickly ,frame simple, motion steady. Failure rate is low and easy to clean maintenance.
● Can choose transmission line materials and air-blower Feeding. Suitable to waste cardboard recycling companies, plastic, fabric large garbage disposal sites and so on.
● Adjustable bales length and bales quantity accumulating function
make the operation of the machine more convenient
● Automatically detect and show the errors of the machine which
improve the machine inspection efficiency
● International standard electric circuit layout, graphic
operation instruction and detailed parts marks makes the operation
been more easily understanding and improves the maintenance
efficiency
NKW220Q
Item | Name | parameter |
mainframe parameter | Bale size | 1100mm(W)×1100mm(H)×~1250mm(L) |
Material type | OCC Newspaper, Cardboard ,Soft Film, Plastic, | |
Material density | 600~700Kg/m3(Moistures 12-18%) | |
Feed opening size | 2400mm×1100mm | |
Main motor power | 45KW×2sets | |
Main cylinder | YG350/230-2900 | |
Main cylinder force | 200T | |
Max working force | 30.5MPa | |
Mainframe weight(T) | About 28 tons | |
Capacity | 20-25 ton per hour | |
Oil tank | 2m3 | |
Mainframe size | About 11.5×4.8×5.8M(L×W×H) | |
Tie wire line | 5 line φ2.75~φ3.0mm3 iron wire | |
Pressure time | ≤35S/ (go and back for empty load) | |
Chain conveyor technology | Model | NK-III |
Conveyor weight | About 11 tons | |
Conveyor size | 2000*14000MM | |
terra hole size | 7.303M(L)×3.3M(W)×1.2M(deep) | |
Conveyor motor | 11KW | |
Cool tower | Cooling system | Oil Chiller +fan Cooler |
![]() |
