| Categories | Belt Drying Equipment |
|---|---|
| Brand Name: | ShouKe |
| Certification: | ISO SGS |
| Place of Origin: | Sichuan |
| MOQ: | 1 |
| Price: | $19900-39900 Sets |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 Sets Years |
| Delivery Time: | 10 Work Days |
| Product name: | Continuous Belt Drying Equipment |
| Power: | 7.5kw |
| Field of application: | chemical industry |
| Structural form multilayer tape: | multilayer tape |
| Weight: | 1200kg |
| Drying time: | 0.4-1.2h |
Description:
The use of an intelligent control system can ensure the
temperature, duration, air volume, and other parameters controlled
in the drying process.
Cost saving: the whole set of equipment can be completed by only
one person, and the drying time is shortened, thus saving labor and
time cost.
High heat energy conversion rate: The heat exchange device
independently developed can be matched with various heat sources,
and the heat energy conversion rate is up to 95%.
Specifications:
| Model | DW2×6m | DW2×8m | DW2×10m | DW2×12m | DW2×14m | DW2×16m | |
| Area of dry | 3 layers | 29㎡ | 40㎡ | 51㎡ | 62㎡ | 73㎡ | 83㎡ |
| 4 layers | 39㎡ | 53㎡ | 68㎡ | 83㎡ | 97㎡ | 110㎡ | |
| 5 layers | 48㎡ | 66㎡ | 85㎡ | 103㎡ | 121㎡ | 138㎡ | |
| 6layers | 57㎡ | 79㎡ | 102㎡ | 124㎡ | 145㎡ | 165㎡ | |
| The thickness of the material | 50---150mm | ||||||
| Operation temperature | 40---120℃ | ||||||
| Drying time | 0.5——5 hour or 3——15 hour | ||||||
| Motor power | 1.1kw | 1.5kw | 1.5kw | 1.5kw | 2.2kw | 3kw | |
| Evaporation, capacity | 200-400kg/h | 300-600kg/h | 400-700kg/h | 500-800kg/h | 600-1000kg/h | 700-1200kg/h | |
| Size of hot blast stove | 1.2×2.5×1.7 | 1.2×2.7×1.9 | 1.3×3×2 | 1.3×3×3 | 1.6×3.5×2.2 | 1.6×3.7×2.2 | |
| Fan | 8C-15kw | 10C-15kw | 10C-22kw | 10C-37kw | 12C-30kw | 12C-45kw | |
| Output conveyor | 1.1kw | ||||||
| Total power | 18kw | 18.4kw | 26kw | 41kw | 35.1kw | 46.7kw | |
MATERIAL APPLICATION
COMPANY PROFILE
PATENT CERTIFICATE
SHIPMENT AND PACKGAGE
Packaging And Delivery Details:
1. Standard import and export wooden case
2. According to customer requirements, the packaging method can be negotiated.
|
