Copper Sulfate Spiral Flash Dryer Machine Iron Oxide Strong Disintegrating System

Copper Sulfate, Iron Oxide Spin Flash Dryer, Steam Heating

Products descriptions

The XSG series spin flash dryer is driven by the hot air tangentially into the bottom of the dryer to form a powerful rotating wind field driven by the agitator. The paste material enters the dryer from the screw feeder. Under the strong action of the high-speed rotating stirring paddle, the material is dispersed under the action of impact, friction and shearing force. The block material is quickly crushed, fully contacted with hot air and heated ,dry.

products Principle

Hot air enters into drying chamber from the bottom of dryer with appropriate spouting speed. Raw material is crushed by dis-integrator and dried by hot air. After being crushed, raw material could have bigger surface area, bigger surface area of raw material and speed difference between raw material with hot air increase drying efficiency.

Products Features

1 There are several feeding systems available, we can get stable stable feeding without bridging phenomenon

2 There has cooling system on agitating part of dryer, avoiding over-heat of raw material.

3 Special designed gas sealing device and shaft cooling device to lengthen life span of driving system.

4 Special designed air distribution system, which could reduce air pressure drop, improve efficiency of hot air

5 There has classification ring in dryer chamber, size and final moisture content of product is adjustable.

6 It could increase bulk density of product compared with other drying equipments

7 There has high spiral air speed inside dryer, drying time is short, it could prevent wall-stick problem, and metamorphism of heat-sensitive material.

8 There has air blowing system, blowing air from bottom of dryer with 30-60m/s speed, it could prevent powder back to hot air pipe.

9 relatively low outlet air temperature, to improve drying efficiency.

10 Strong disintegrating system and spiral hot air could crush material, and obtain fine, uniform product.

Products parameters

Note: The table is based on 200℃ inlet air temperature and 80℃ outlet temperature. Final dryer model is depends on raw material feature.

Spin Flash Dryer ordering instructions
◎Material liquid name, physical properties: solid content (or water content), viscosity, surface tension, PH value.
◎Dry powder capacity, allowable residual water content, particle size, and allowable maximum temperature.
◎Production, working hours every day.
◎Available energy: steam pressure availability, electrical capacity, coal, oil, and gas consumption.
◎Control requirements: Whether the inlet and outlet temperatures need to be controlled automatically.
◎Powder collection requirements: environmental requirements for exhaust gas.
◎Other special requirements.

Details Image

Company Profile

      Changzhou Senmao Machinery Equipment Co., Ltd. is located in Zhenglu Town, an industrial center in Changzhou, Jiangsu Province. It is only 6 kilometers from Hengshan Crossing of Shanghai-Nanjing Expressway and Jiangyin Yangtze River Highway in the east, 18 kilometers from Changzhou Railway Station in the west and 30 kilometers from Changzhou Benniu International Airport. The transportation is very convenient. Changzhou Senmao Machinery and Equipment is a professional drying enterprise committed to the design, research and development, production and after-sales of all kinds of drying equipment in new materials, new energy, pharmaceutical, food, chemical and other industries at home and abroad.

      The main products: fluidized bed drying equipment, spray drying equipment, precision drying grain equipment, (double cone, disc, screw belt mixing, rake type, low temperature pulse high efficiency) vacuum drying equipment, flash air drying equipment, belt drying equipment research and development, non-standard design and production. Xiongguan road is really like iron, and now step over from the beginning. Senmao enterprise will be "cast with ingenuity, create The Times, lead the future" as the vision goal; The company has gathered a group of high-level, high-quality professional talents; We have no career, only career, do great things in the heart will never change; Born because of love, wind and rain together, and struggle for strong forest!
      In this new historical period, Senmao will use practical actions to fulfill our mission "continue to create value for customers, strive to realize the dream for employees, and wholeheartedly build an excellent platform for the society"!
      SENMAO Enterprise is willing to work with you hand in hand, common development, common progress!

Product packaging

*Usually small machine will be packed in the wooden case, and we can also pack it according to customers special request.
*If machine is big, we will fix the machine inside container with steel wires and nails. Machine won't move inside the container.
