24V Waterproof Double-layer LED FPC Flexible Printed Circuit for High Performance LED Light Strips

24V Waterproof Double-layer LED FPC Flexible Printed Circuit for High Performance LED Light Strips

24V Waterproof Double-layer LED FPC Flexible Printed Circuit for High Performance LED Light Strips
24V Waterproof Double-layer LED FPC Flexible Printed Circuit for High Performance LED Light Strips
Categories Chip on FPC
Brand Name: HONGQI
Model Number: HQ3048
Certification: UL E477885 IATF16949 GB/T 16949
Place of Origin: GuangDong,China
MOQ: 3000pcs
Price: negotiable
Payment Terms: L/C,D/A,T/T
Supply Ability: 1000000 Pieces per month
Delivery Time: negotiable
Packaging Details: Packed with strong Paper cases
Smp: Support
Product Type: Flexible Printed Circuit
Solder Mask Color: Yellow, Black, White
Marketing Method: Factory Direct Sales
The Min Hole: 0.23mm
Waterproof: Yes
Smt And Dip: Support
Durability: Long-lasting
Mechanical Rigidity: Flexible
Width: 8mm
Status Code: 403
Voltage Rating: 12V
Processing Technology: electrolytic foil
Application: Indoor and outdoor lighting
Number Of Leds: 15
Contact Now
Company Info.
Guangdong HongQi Advanced Materials Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

24V Waterproof Double-layer LED FPC Flexible Printed Circuit for High Performance LED Light Strips

SMD 2835 LED Strip with Transistor | 15LEDs 10x503mm 24V High Performance
High-performance LED light strip FPC combining structural integrity, mechanical durability, and environmental adaptability for demanding lighting applications.
Product Overview
ParameterSpecification
Product ModelHQ30156
Product NameLED Light Strip FPC
Circuit StructureDouble-layer circuit board
Surface CoatingDouble-sided black solder mask; black silk screen printing
Antioxidant TreatmentOSP (Organic Solderability Preservative)
Core PerformanceSuperior flexibility; excellent bending fatigue resistance; stable electrical conductivity
Design StandardCompliant with IPC-2221 general printed circuit board design specifications
Technical Specifications & Customization
Dimensional Parameters
  • Precision FPC: Maximum dimensions 240×500mm; no minimum size restriction
  • Roll-type FPC: Maximum width 240mm; maximum length 100 meters
Circuit Layer Configurations
  • Single-layer FPC: Cost-efficient for low-complexity circuits
  • Double-layer FPC: Enhanced connectivity for high-integration applications
  • Multi-layer FPC: Customizable for ultra-high-complexity scenarios
Solder Mask Options
  • Yellow Solder Mask: Universal solution for general-purpose applications
  • Black Solder Mask: Superior light absorption for high-end lighting systems
  • White Solder Mask: High-reflectivity for professional lighting fixtures
Copper Foil Thickness
  • Precision FPC: 12μm, 18μm, 35μm options
  • Standard FPC: 18μm, 25μm, 35μm, 50μm options
Minimum Line Width/Spacing
Controlled to 3mil (0.076mm) as recommended practical limit for optimal manufacturing yield and reliability.
Core Performance & Quality Assurance
Flexibility & Bending Durability
Validated through rigorous testing with minimum 10,000 bending cycles per IPC standards, ensuring resistance to fatigue failure in dynamic applications.
Manufacturing Capabilities
20,000 sqm facility with 800+ employees and monthly output exceeding 5 million square meters, equipped with state-of-the-art German, Japanese, and Taiwanese machinery.
Customization Services
Technical Consultation
16 years of engineering expertise providing tailored solutions, drawing optimization, and material selection guidance.
Sample Fabrication
Expedited production line with 5-7 day lead time for double-layer samples and 3-5 days for single-layer samples, all validated through comprehensive testing.
Integrated Manufacturing
One-stop services covering substrate fabrication, precision circuit routing, custom mold development, and high-precision assembly with ±0.02mm tolerance.
Certifications & Compliance
ISO 9001 certified • UL 94 flame-retardant • RoHS compliant • REACH compliant
All materials meet international environmental standards with no restricted substances
Product images may show minor color variations due to lighting conditions. Actual products shall prevail. Our FPC portfolio undergoes regular technical upgrades to enhance performance and expand application scope.
