144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use

144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use

144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use
144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use
Categories Perkins Diesel Generators
Brand Name: PERKINS
Model Number: 1106A - 70TAG3
Certification: CE
Place of Origin: China
Supply Ability: 500pcs per month
Delivery Time: 30 days
Packaging Details: Plywood
Canopy: Customized
Warranty: 12 Months/1000 Hours
Type: Silent(super Silent)or Open, Silent, Etc, In-line/6-Cylinder/4-Stroke/4-Valve/19L, Soundproof Canopy(Silent)
Control Panel: LCD Digital Display, Deepsea, ComAp, Deepsea / ComAp / Harsen / Smartgen 6110, Smartgen
Output Type: AC Single/Three Phase
Controller: Deepsea/Smartgen/etc
Application: Indursty Bank Etc
Rated Voltage: 400/230V, 110-480V, 220V / 380V, 110V / 240V, 380V
Alternator: Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford Or Newtec, Engga
Product Name: Customizable PERKINS 108kW 135KVA diesel generators, for household use, industrial use, hospital use, and construction sites.
Color: Customers' Requirement
Frequency: 50/60HZ
Rated Power: 180kva
Engine: Original PERKINS
Cooling Method: Water-cooling System
Contact Now
Company Info.
FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use

144kW 180KVA Customizable Silent Diesel Generator Sets
Hot sale customizable silent diesel generator sets with automatic transfer switch option for home use
Product Introduction
Our 144kW 180KVA BOBIG PERKINS diesel generator (Model: 1106A-70TAG3) is designed to provide reliable power for a wide range of applications. Backed by the renowned PERKINS brand, it offers high-quality performance and long-term durability.
Key Features
Power Performance
Rated Power: With a rated power of 144kW (180KVA), it can meet the power needs of various industrial, commercial, and residential applications. The prime power output is stable and efficient, ensuring continuous operation even under heavy loads.
Frequency: The generator operates at a standard frequency of 50Hz, which is suitable for most electrical equipment in the market.
Engine Excellence
Engine Model: Powered by the 1106A-70TAG3 PERKINS engine, it combines advanced technology and high-quality manufacturing. The engine is known for its high torque, fuel efficiency, and low emissions.
Engine Speed: Running at 1500 RPM, it provides a smooth and consistent power supply while minimizing wear and tear on the engine components.
Applicable Standards
Our generator complies with multiple international and national standards, including ISO 8528-5:2018, GB/T2820.5-2009, and CE. These certifications guarantee the quality, safety, and reliability of the product.
Environmental Adaptability
Ambient Temperature: It can operate effectively in an ambient temperature range of +5°C to +40°C.
Altitude: The generator is suitable for use at altitudes of up to 1000m. If your environmental conditions are different, our sales team is ready to assist you with customized solutions.
Technical Specifications
General Information
ParameterPrime PowerStandby Power
Rated Power (kVA)180198
Power Rating (kW)144158
Frequency (Hz)50
Engine Model1106A-70TAG3
Engine Speed (RPM)1500
Phase3
PF0.8
Control SystemDigital
Rated Voltage (V)400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time≥ 8h @ 75% load
PRP: Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.
ESP: The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Dimension and Weight
ModelBP198 (Open type)BP198S (Silent type)
Length (mm)24003250
Width (mm)8201040
Height (mm)15501500
Tank Capacity (L)331331
Engine Specifications
Engine Model & Manufacturer1106A-70TAG3 (PERKINS)
Emission Certification----
Number of Cylinders6
Cylinder ArrangementVertical inline
CycleFour stroke
AspirationTurbocharged and air charge cooled
Bore x Stroke105 x 135 mm
Cubic Capacity7.01 L
Compression Ratio16.0:1
Prime Power/Speed157.7 kW/1500 rpm
Standby Power/Speed175.2 kW/1500 rpm
Governor TypeMechanical
Cooling SystemForce Water Cooling Cycle
Transient Frequency Deviation-0.833333333
Total Lubrication System Capacity12.5 L
Coolant Capacity (engine only)18.0 L
Fuel Consumption (100% load)209 g/kWh @1500 rpm
Starter MotorDC 24V
Charge AlternatorDC 24V
Alternator Specifications
Alternator BrandBOBIG
Alternator ManufacturerFUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator ModelBW-274G
Alternator Rated Power144kw/180kva
Rated Voltage (V)230v/400v
Rated Frequency50hz
Connecting Type3 Phase and 4 W
Number of Bearing1
Protection GradeIP23
Altitude≤1000m
Exciter TypeBrushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation ClassH class
Telephone Influence Factor (TIF)≤50
THF≤2%
Voltage Regulation, Steady State≤±1%
Transient State Voltage≤-15%~+20%
Customization & Features
We support customization and OEM services. (There will be design drawings.)
All the units are equipped with original power supplies and come with the standard DSE 6120 controller. (Engine is optional, generator is optional, controller is optional)
BOBIG Diesel Generator Controller and Components
Packaging & Shipping
Plywood case, 10~15 working days after receiving customer's order.
Certifications
BOBIG Quality Certification BOBIG International Standards Certification
Applications
This diesel generator is ideal for a variety of applications, such as:
  • Industrial Use: It can be used as a backup power source for factories, ensuring continuous production during power outages.
  • Commercial Buildings: Office buildings, shopping malls, and hotels can rely on it to maintain essential services like lighting, elevators, and security systems.
  • Residential Areas: Provide reliable power to residential communities, especially in areas with unstable power grids.
Warranty and After-sales Service
We offer a comprehensive warranty for our diesel generators. Our professional after-sales service team is available 24/7 to provide technical support, maintenance, and repair services to ensure your peace of mind.
BOBIG products have guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, we will provide the free easy-damageable spare parts, caused by our quality of production or raw material. After expiration, we provide cost spare parts maintenance.
Why Choose Us
  • Brand Reputation: Engine is a well-known and trusted brand in the diesel generator industry, with a long history of producing high-quality products.
  • Quality Assurance: Our products are manufactured in strict accordance with international standards, and each generator undergoes rigorous quality inspections before leaving the factory.
  • Customization Options: We understand that different customers have different needs. Our team can provide customized solutions based on your specific requirements.
Frequently Asked Questions
1. What is your MOQ, payment method, delivery time?
Answer: Our MOQ is only 1 set. Payment method usually is 30% T/T as deposit, 70% balance T/T before delivering. Or 100% L/C, trade assurance, PayPal, Western Union. Delivery period normally will be 10~15 working days after receiving customer's deposit.
2. Which port do you often use when export?
Answer: Fuzhou port, Fujian province or as customer request.
3. Is there any spare parts you can provide along with generators to make the maintenance convenient?
Answer: We can provide regular engine's air filter, water filter, fuel filter, oil filter to customers for self-maintenance.
4. Can you offer parts to us if we need?
Answer: Yes, we can offer parts to you at any time, not limited in warranty time. Usually the parts can be sent out during 3-5 days.
5. For voltage, frequency, tank capacity, phase and color, can you made accord with our requests?
Answer: Yes, they can be made accord with your need.
6. If I want to be your products distributor in our country, what is your distribution policy?
Answer: Welcomes everybody join us and distribute products worldwide. We can issue authority certificates and sign agreement with you accordingly.
