Hypoid Gear Set Bevel Wheel And Pinion For Hollow Rotary Acuator Gearbox

Hypoid Gear Set Bevel Wheel And Pinion For Hollow Rotary Acuator Gearbox

The reason why hypoid gears are particularly suitable for hollow rotating platforms is mainly due to their unique geometric structure and motion characteristics. These characteristics allow hypoid gears to maintain high efficiency and high load capacity while allowing relative motion between axes and Angle changes. The following are several key points why hypoid gears are suitable for hollow rotating platforms:

• Axis misalignment tolerance: Hollow rotating platforms often need to be able to rotate at different angles and positions, which means the gear system must be able to tolerate misalignment between axes. The design of hypoid gears allows for some axis offset so they can function properly even if the axes are not exactly parallel or there is relative motion between the axes.
• High load capacity: Hollow rotating platforms often need to bear larger loads. Due to their special tooth shape and contact pattern, hypoid gears are able to withstand large moments, which makes them ideal for heavy-duty applications.
• Smooth operation: The meshing of the hypoid gears is continuous, and the contact points roll between the gears, which helps reduce vibration and noise, providing smoother motion, which is crucial for precise control of hollow rotating platforms.
• Compact design: Since the hypoid gear can work with axis deviation, it can be more compact in design, which is very beneficial for the overall size and weight control of the hollow rotating platform.
• Long life and low miantenance: The design of hypoid gears helps spread loads and reduce wear on the gear surface, thus extending the life of the gear and reducing the need for maintenance.
• Flexibility and adaptability: The hollow rotating platform may need to be adjusted and reconfigured according to different application scenarios. The flexibility of hypoid gears allows the platform to adapt to different working conditions and requirements.

Taken together, these characteristics of hypoid gears make them an ideal choice for hollow rotating platforms, as they can provide efficient, smooth, and reliable rotational motion while also being able to adapt to changing demands of the platform in different working environments.

DINGSCO

We're the production R&D base specializing in professional design, reserch, manufacture and sales of high-quality small module spiral bevel gears and high reduction hypoid gears and cylindrical gears. We have strong scientific research and development capabilities and is also equipped a full set of advanced equipment including seven-axis five-linkage CNC spiral bevel gear grinding machines and gear milling machines. By making the best use of the scientific and technological achievements and equipment of the Gear Research Institute of Central South University, machanical processing, heat treatment and testing. We have developed high-quality products featuring high reduction, high speed, heavy load, low noise and less teeth for users.

Non-standard customization of Dinghan gears, our company has a complete set of software to realize digital closed-loop manufacturing of spiral bevel gears, Functions such as gear design, strength calculation, contact analysis, tool calculation, tooth profile error reversal, etc. can be realized. Machining methods include five tools machining(fixed setting) & G-plete of tapper , spiral format tilt(SFT) method & hypoid format tilt (HFT) method of Cycloid equidep, etc.

Our company was formerly known as Changsha Double Star Gear Industrial Co., Ltd, which was established in 1994. It is a directly affiliated university-run enterprise founded by Central South University Professor Zeng Tao, the leading expert on spiral bevel gears in China. It was later renamed as Changsha Senjie Gear Co., Ltd (abbreviated as "CSG") in 2016. CSG is a production R&D base specializing in professional design, reserch, manufacture and sales of high-quality small module spiral bevel gears and high reduction hypoid gears and cylindrical gears. In 2023, Hunan Dinghan New Material Technology Co., Ltd. was established as a specialized international export business department. CSG has strong scientific research and development capabilities and is also equipped a full set of advanced equipment including seven-axis five-linkage CNC spiral bevel gear grinding machines and gear milling machines. By making the best use of the scientific and technological achievements and equipment of the Gear Research Institute of Central South University, machanical processing, heat treatment and testing. We have developed high-quality products featuring high reduction, high speed, heavy load, low noise and less teeth for users.

With the quality policy of "scientific and technological innovation, quality first, being first-class firm and customer‘s satisfaction", we have won the trust of well-known domestic and abroad enterprises with stable and excellent quality. It is committed to be a pioneer of the industry of China's small-module spiral bevel gears, and is dedicated to providing service for any related industry requiring industrial robots, CNC turning and milling compound power tool turrets, industrial sewing machines, reducers, bicycles, power tools and aeromodelling. We sincerely look forward to your cooperation!
