Cu Prothal 10 / NC 6 / CuNi6 Alloy 60 Ribbon Wire 0.3*4mm For Electrical Components

Cu Prothal 10 / NC 6 / CuNi6 (Alloy60 ) Ribbon Wire 0.3*4mm For Electrical Components​

Product Description:

CuNi6 alloy wire is also known as "Cu Prothal 10" and "NC 6" in addition to being called CuNi6. These are some of the other common names for this alloy wire.

Chemical Content, %

Mechanical Properties

1. Composition: It is a copper-nickel alloy with approximately 94% copper and 6% nickel.

2. Physical properties:

• Density: It has a density of about 8.9 g/cm³.
• Resistivity: The electrical resistivity at 20 °C is 0.1 Ω·mm²/m, which is relatively higher than that of pure copper, making it suitable for certain resistance applications.
• Melting point: The melting point is around 1095 °C.
• Coefficient of thermal expansion: From 20 °C to 400 °C, the coefficient of thermal expansion is 17.5 × 10⁻⁶ /K.
• Specific heat capacity: At 20 °C, the specific heat capacity is 0.380 J/gK

​3. Mechanical properties:

• Strength: It has a yield strength of 110 MPa and a tensile strength of 250 MPa (for a 1.0 mm sample), showing relatively good mechanical strength.
• Elongation: The elongation is 25% (for a 1.0 mm sample), indicating a certain degree of ductility.

4. Other properties:

• Temperature resistance: It can be used at temperatures up to 220 °C and has good stability at high temperatures.
• Magnetic properties: It is non-magnetic.
• Corrosion resistance: It has good corrosion resistance in the atmosphere at 20 °C, but the corrosion resistance is relatively poor in some specific gas environments such as those containing sulfur.

Main characters of copper nickel alloy grades:

Tankii advantages:

a) Tankii can provide high quality material, excellent design, precise manufacturing,complete specifications, considerate and integrity serivices.
b) Tankii can provide all kinds of electric heating alloy material and elements, including customized products.
c) Tankii can provide a complete solution for you.
d) OEM service can be provided.
e) Product selection
f) Process optimization
g) New product development

Product picture: round wire

Flat wire:

Package:

Shanghai Tankii Alloy Material Co., Ltd. focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy), thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate.

Please contact us for quotation.

Shanghai Tankii Alloy Material Co., Ltd.specialized in production of Resistance Heating Alloy, Nickel Chromium Alloy, Iron Chromium Aluminum Alloy, Nickel Aluminum Alloy, Manganin, Copper Nickel Alloy, thermocouple wire, pure nickel and other precision alloy materials in the form of round wire, ribbon wire, sheet, tape, strip, rod and plate.

We’ve already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system.

We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.

Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over forty years in this field. During forty years, hundreds of management elites and high science and technology talents were employed.They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market.

Based on the principle of “first quality, sincere service”, our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.

Our products, such us nichrome wire, nichrome strip, fecral wire, fecral strip, thermocouple wire, nickel wire, nickel strip have been exported to Europe, USA, India, Southest Asia, South America,etc.

We are willing to establish strong and long-time partnership with our customers

• Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers
• Quality with end to end production control
• Technical support and Customer Service
