| Categories | Silicone Potting Compound |
|---|---|
| Brand Name: | Hanast |
| Model Number: | HN-8808 |
| Certification: | ROHS，SGS |
| Place of Origin: | Guangdong, China |
| MOQ: | 1 kilogram |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Packaging Details: | 25KG/ Iron Drum |
| Type: | two parts potting material |
| temperature range: | - 57°C to 250°C |
| Feature: | Non-toxic, odorless, non-corrosive, non-swelling |
| Application: | sealing, electrical, potting, insulation electronic appliances |
| Appearance: | Transparent, White, Black Flowing Liquid |
| Viscosity (before curing) (mPa.S）: | A：2000 B:50 |
| Shaw Hardness (JIS A): | 25 shore A |
| Mix ratio: | 10：1 |
| Dielectric Constant (1MHZ): | 2.5 - 3.0 |
| Thermal Conductivity (w / m.k): | 0.1 - 0.20 |
| Company Info. |
| Shenzhen Hanast New Material co.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
Factory Supply 2 Part RTV Silicone Led Module Potting Insulation Waterproof Silicone Potting Material 10:1 Electronic clear Potting Compound
Product description of 10:1 silicone potting compound
HN-8808AB is a two-component condensation type room temperature curing silicone rubber, also known as RTV 2 Liquid Silicone Rubber, composed of two parts of A and B. After the A and B components are mixed at 10:1 (mixed ratio), they solidify into a high-performance elastomer through a condensation reaction.
Product Features of 10:1 silicone potting compound
1) Good adhesion, no corrosion
2) solid Small chemical shrinkage,
3) no heat release, good insulation,
4) wide temperature range (-50℃-200℃),
5) waterproof and moisture-proof
Main Application of 10:1 silicone potting compound
It is mainly used in circuit boards, LED power supplies, automotive electronic modules, power module.
Technical Sheet of 10:1 silicone potting compound
| Before Mixing | ||
| A | B | |
| Exterior | black liquid | Transparent liquid |
| Base chemical composition | Polysiloxane | Polysiloxane |
| Viscosity (cP) (GB/2794-1995) | 2000-2800 | 20-30 |
| Density (g/cm³) (GB/2794-1995) | 1.42±0.02 | - |
| A+B after mixing | ||
| Exterior | black liquid | |
| Base chemical composition | Polysiloxane (Silicone) | |
| Viscosity (cP) (GB/2794-1995) | 2000-2600mpa's | |
| Density (g/cm³) (GB/2794-1995) | 1.40±0.02 | |
| Operating time (25℃, min) | 40-60 | |
| Curing time (25℃, h) | 4-6 | |
| Hardness (shore A) (GB/T531-1999) | 30-40 | |
| Volume resistivity Ω·cm (GB/T 31838.2-2019) | ≥5.0×10 14 |
| Thermal conductivity (W/M▪K) (GB/T 38712-2020) | 0.5±0.1 |
| Dielectric strength (kv/mm) | ≥14 |
| Dielectric constant | ≤3.5 |
| Elongation at break (%) | ≤100% |
Packaging Method of 10:1 silicone potting compound
50kg/set (component A 25kg + component B 25kg)
40kg/set (component A 20kg + component B 20kg)
How to use 10:1 silicone potting compound
Attention
1. The rubber material should be sealed and stored. Use the mixed glue at one time to avoid waste.
2. 10:1 colloid cannot be heated to accelerate solidification after mixing.
3. This product is a non-dangerous product, but please keep it out of your mouth and eyes.
4. This product is non-toxic and non-dangerous. Avoid rain and exposure. Store in a cool and dry place. The shelf life is6months (best use period3 within months)
