| Categories | Lead Acid Battery |
|---|---|
| name: | Lead Acid Deep Cycle Battery |
| model: | MITPB12-12200 |
| Rated Voltage: | 12V |
| Capacity: | 200Ah |
| Certified: | UL ,CE |
| Compliance with: | IEC 61056, GB/T 19639 |
| Place of Origin: | China |
| Brand Name: | MITSCN |
| Certification: | ISO |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | Solar Panel Carton box by pallet or ply wooden box |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000 Piece/Pieces per Month |
| Company Info. |
| Beijing MITSCN Co., Ltd. |
| View Contact Details |
| Product List |
MITPB12-12200 12-200AT BATTERY
Telecom Control Equipment
UPS systems
Communication Equipment
Medical Equipment
Emergency Power Systems
Security Systems
Cable TV
Railway System
GENERAL FEATURES
GENERAL FEATURES
ELECTRICAL CHARACTERISTICS | STC*
| Nominal Voltage | 12V(6 cells per unit) | |||
| Design Floating Life @25℃ | 12 Years | |||
| Nominal Capacity @25℃(10 hour rate@20.00A,10.80V) | 200Ah | |||
Capacity @25℃ | 20 hour rate (10.70A,10.5V) | 214.0Ah | ||
| 5 hour rate (35.2A,10.5V) | 176.0Ah | |||
| 1 hour rate (127.6A,9.6V) | 127.6Ah | |||
| Internal Resistance | Full Charged Battery@25℃ | ≤3.9mΩ | ||
Ambient Temperature | Discharge | -30℃~60℃ | ||
| Charge | -30℃~60℃ | |||
| Storage | -30℃~60℃ | |||
| Max. Discharge Current@25℃ | 2000A(5s) | |||
Capacity affected by Temperature (10 hr Capacity ) | 40℃ | 108% | ||
| 25℃ | 100% | |||
| 0℃ | 90% | |||
| -15℃ | 70% | |||
| Self-Discharge@25℃ per Month | 3% | |||
Charge (Constant Voltage) @25℃ | Standby Use | Initial Charging Current Less than 40A Voltage 13.6-13.8V | ||
Cycle Use | Initial Charging Current Less than 40A Voltage 14.4-14.9V | |||
|
