TLVH431AQDBVRQ1 SOT23-5 Shunt Voltage Reference IC VREF SHUNT

Categories	EMMC Memory Chip
Brand Name:	original
Model Number:	TLVH431AQDBVRQ1
Certification:	original
Place of Origin:	original
MOQ:	1
Price:	negotiation
Payment Terms:	T/T, L/C
Supply Ability:	100,000
Delivery Time:	1-3working days
Packaging Details:	carton box
Product Status:	Active
Reference Type:	Shunt
Output Type:	Adjustable
Voltage - Output (Min/Fixed):	1.24V
Voltage - Output (Max):	18 V
Current - Output:	70 mA
Tolerance:	±1%
Current - Cathode:	100 µA

Contact Now

Add to Cart

Company Info.

SZ ADE Electronics Co., Ltd

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

TLVH431AQDBVRQ1 SOT23-5 Shunt Voltage Reference IC VREF SHUNT

TLVH431AQDBVRQ1 Emmc Memory Chip Ic Vref Shunt Adj 1% Sot23-5

Shunt Voltage Reference IC Adjustable 1.24V 18 VV ±1% 70 mA SOT-23-5

Specifications of TLVH431AQDBVRQ1

TYPE	DESCRIPTION
Category	Integrated Circuits (ICs)
	Power Management (PMIC)
	Voltage Reference
Mfr	Texas Instruments
Series	Automotive, AEC-Q100
Package	Tape & Reel (TR)
	Cut Tape (CT)
	Digi-Reel®
Product Status	Active
Reference Type	Shunt
Output Type	Adjustable
Voltage - Output (Min/Fixed)	1.24V
Voltage - Output (Max)	18 V
Current - Output	70 mA
Tolerance	±1%
Current - Cathode	100 µA
Operating Temperature	-40°C ~ 125°C (TA)
Mounting Type	Surface Mount
Package / Case	SC-74A, SOT-753
Supplier Device Package	SOT-23-5
Base Product Number	TLVH431

Features of TLVH431AQDBVRQ1

• Qualified for Automotive Applications

• Low-Voltage Operation: Down to 1.24 V

• Reference Voltage Tolerances at 25°C

– 0.5% for B Grade

– 1% for A Grade

• Adjustable Output Voltage, VO = VREF to 18 V

• Wide Operating Cathode Current Range:

100 μA to 70 mA

• 0.25-Ω Typical Output Impedance

• –40°C to 125°C Specifications

Applications of TLVH431AQDBVRQ1

The TLVH431 devices are low-voltage 3-terminal adjustable voltage references, with thermal stabilityspecified over the automotive temperature range. Output voltage can be set to any value between V REF (1.24 V) and 18 V with two external resistors (see Figure 2). These devices operate from a lower voltage (1.24 V) than the widely used TL431 and TL1431 shunt-regulator references.

Environmental & Export Classifications of TLVH431AQDBVRQ1

ATTRIBUTE	DESCRIPTION
RoHS Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
