Food Grade Automatic Bottle Packing Machine , 5L Bottling Filling Packing Machine

Automatic Drinking Water 5L Bottling Filling Packing Machine

Introduction

The drinking water 5L bottling packing machine is from the washing, filling ,capping and conveyor line, linear motion and pneumatic operation, PLC control, high degree of automation is a square bottle, irregular bottle is the ideal equipment, production may be appropriate to adjust the equipment package the materials used in all high-quality stainless steel.

Main features

1). Washing machine

The washing machine connect with empty bottles conveyor frame, when empty bottle feeding to washing machine extent, through photoelectrical reaction, circuit control system command pneumatic electromagnetic valve movements, let the clip bottles of cylinder clip the bottle, then the overturn cylinder operate, the bottleneck turn down, then the pure water pump open, spurt pure water to the bottle, after 30s, stop it, the overturn cylinders reset, input the conveyor system and go to filling machine.

2). Filling machine

After-washing empty bottle come to the filling machine through wheel, two push-barrel cylinders operate, then the bottle arrive filling part, the bottle bottom separate the conveyor belt. After filling, the bottle drop on the conveyor belt. Output to the capping part.

3). Capping machine

The screw capping machine is made of screw capping heads frame, after the filled bottle convey to the screw capping machine station, through air cylinder start to screw cap, again and again, the finished bottle output to the warehouse and check.

Main Specification

Touch screen: Mitsubishi, Thinget or Weinview
PLC program controller: Mitsubishi or Omron
Inverter: Mitsubishi or Omron
Photoelectrical controller: AUTONICS
Other electrical components: Schneider
Pneumatic component: Airtac
Pump: Nanfang

Technical Parameters

Welcome your inquiry !

Jiangsu Zhongyin Machinery Co., Ltd. is located in Donglai Town, Zhangjiagang City, Jiangsu Province. It has international standard workshop more than 15000 square meters. It is one of the professional beverage packaging machinery manufacturers with collecting research, development and manufacturing. It is China's best beverage machinery equipment suppliers. As liquid packaging industry enterprise, the drink service network is all over the world more than 30 countries and regions, products are widely used in drinks, flavor, cosmetic, beer, milk, and pharmaceutical industries.

Gathering the domestic famous machinery manufacturing enterprise, which have many years' staff more than 60 from machinery, technology and automatic control these 3 fields. It's the strong team of liquid (drink) packaging machinery industry in China, the existing 2 food engineering doctor, 5 masters, 12 senior engineers, can provide users with: Market positioning analysis, designing, engineer training and a set of turnkey solution project and related services.

Modern factory, all kinds of advanced processing equipment and testing equipment, experienced technicians, scientific and strict management, constitute the drink mechanical excellence in product manufacturing system. It also provides Zhongyin Machinery product's quality in the most powerful guarantee.
