| Categories | Clear PETG Sheet |
|---|---|
| Place of Origin: | Jiangsu, China |
| Brand Name: | Jiaou |
| Model Number: | None |
| Supply Ability: | 100 Tons Per Day |
| MOQ: | 1000 kilograms |
| Price: | Negociated |
| Certification: | FDA, GRS, Reach, RoHS, ISO9001 |
| Packaging Details: | Sample: A4 size rigid PETG with PP bag in box Sheet packing: 30kg per bag or as your requirement Pallets packing: 500- 2000kg per wooden pallet Container loading: 20 tons as normal |
| Payment Terms: | T/T |
| Delivery Time: | 7 Work Days |
| Product name: | Clear PETG Sheet For Sandwich Containers |
| Material: | PETG |
| Thickness: | 0.18-7mm |
| Size: | 2440mm |
| Other Product Name: | PETG Sheet |
| Origin: | China |
| Color: | Transparent |
| Raw Material: | PETG Resin |
| Application: | For Sandwich Packaging |
| Feature: | Eco-Friendly |
| Sample: | Available |
| Port: | Shanghai, Lianyungang, Zhangjiagang |
Clear PETG Sheet Excellent Clarity PETG Plastic Sheet For Sandwich Lunch Containers
Product Description
PETG sheet is a thermoplastic sheet made by Polyethylene terephthalate resin. PETG offers the capability to produce complex shapes, precise details, deep draws and compound curves without worrying about durability. PETG is easily formed, die-cut and punched. It also brings increased design freedom and lower fabrication costs. In sheet form, PETG has the impact strength and fabrication ease that acrylic can't touch, with the durability to significantly reduce packaging and shipping costs.
| Item | Typical Value |
| Product name | Clear PETG Sheet For Sandwich Containers |
| Width | 300mm - 2100mm |
| Thickness | 0.18mm - 7mm |
| Size | Custom |
| Material | PETG |
| Color | Transparent, Custom |
| Application | Food Packaging |
| Surface | Smooth |
| Feature | Rigid |
| Sample | Available |
• Outstanding thermoforming characteristics, particularly in deep
draw applications
• Good impact resistance
• Less brittle than acrylic
• Resistant to common cleaners used on point of purchase displays
• Allows for rigid thermoforming cycle times
• FDA compliant grades available
• Impact strength greater than acrylic and approaches polycarbonate
• 86% light transparency compared to 87% for polycarbonate and 92%
for acrylic
• Die cuts/punches easily
• Low forming temperature
• Printable
• Chemical resistant
• Self-extinguishing
Technical Data Sheet
| Item | Unit | Typical Value | Testing Method |
| Intrinsic Viscosity | dL/g | 0.750+/-0.015 | Ubbelodhe viscometer |
| Specific Gravity | kg/cm³ | 1.27 | ASTM D792 |
| Moisture Absorption | % | 0.15 | ASTM D570 |
| Tensile Strength@Yield 50mm/min( inch/min) | kgf/cm² | 496 | ASTM D638 |
| Tensile Strength@Break 50mm/min( inch/min) | kgf/cm² | 281 | ASTM D638 |
| Elongation@Yield 50mm/min( 2inch/min) | % | 3.7 | ASTM D638 |
| Elongation@Break 50mm/min(2 inch/min) | % | 136 | ASTM D638 |
| Flexural Strength 1.27mm/min(2 inch/min) | kgf/cm² | 620 | ASTM D790 |
| Flexural Strength 1.27mm/min(3 inch/min) | kgf/cm² | 20800 | ASTM D790 |
| Low temperature falling dart impact | g | 791 | ASTM D358 |
| Atmospheric temperature falling dart | g | 1701 | ASTM D358 |
| Lzod Impact Strength Notched@23 ℃ | J/m | 98 | ASTM D256 |
| Rockwell Hardness | ℃ | 106 | R-scale |
| Heat Distortion Temperature 0.45Mpa(66 psi) | ℃ | 77 | ASTM D648 |
Application For PETG Sheet
PETG is used as a Midrange priced product between Acrylic and Polycarbonate. The clearity of PETG approchies that of Acrylic and Impact Resistance of Polycarbonate. Also is used in Signing, Glazing, POP Displays, etc.
• Sign and graphic holders
• Point of purchase displays
• Merchandisers
• Table top displays
• Table tents
• Product displays
• Trays
Package
FAQ
Q1. Are you a factory or trade company?
A: We are a professional manufacturer with 15 years' experience. If you have interests, welcome to visit our factory.
Q2. Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free, but charge by freight collection.
Q3. How about the lead time?
A: Normal sample supply it at once. Special samples need 3 days. mass production is generally 5-10 working days after receiving your initial payment.
Q4. Do you have any MOQ limits?
A: Normal Only 500kgs, Special colors about 2000kg.
A: 30% T/T in advance, balance before shipment. We accept L/C at Sight.
|
