| Categories | Clear PETG Sheet |
|---|---|
| Place of Origin: | Jiangsu, China |
| Brand Name: | Jiaou |
| Model Number: | PETG sheets |
| Packaging Details: | Sample: A4 size rigid PETG with PP bag in box |
| Supply Ability: | 100 Tons Per Day |
| MOQ: | 10000 pieces |
| Price: | To be negociated |
| Certification: | FDA, GRS, Reach, RoHS, ISO9001 |
| Payment Terms: | T/T, L/C |
| Delivery Time: | To Be Negotiated |
| Product name: | Clear PETG Sheet For Clear Aligners |
| Material: | PETG |
| Processing Service: | Cutting |
| Surface: | Glossy |
| Color: | Custom color available |
| Application: | Clear Aligners |
| Characteristics: | Medical grade |
| Sample: | Available |
| Packing: | Pallets |
| Port: | Shanghai, Ningbo, Lianyungang, Zhangjiagang |
Jiaou New Materials Co., Ltd. now provides GAG flat sheets. Clear thermoplastic flat GAG sheet ratio is available as an alternative to polycarbonate, solid acrylic, and PVC sheets. It has an excellent strength-to-weight ratio, excellent optical clarity, excellent chemical resistance, durability, and fire resistance, and is 100% recyclable.
Product Features
Technical Data Sheet
| Item | Typical Value | Testing Method |
| Intrinsic Viscosity(dL/g) | 0.750+/-0.015 | Ubbelodhe viscometer |
| Specific Gravity(kg/cm³) | 1.27 | ASTM D792 |
| Moisture Absorption(%) | 0.15 | ASTM D570 |
| Tensile Strength@Yield 50mm/min( inch/min)(kgf/cm²) | 496 | ASTM D638 |
| Tensile Strength@Break 50mm/min( inch/min)(kgf/cm²) | 281 | ASTM D638 |
| Elongation@Yield 50mm/min( 2inch/min)(%) | 3.7 | ASTM D638 |
| Elongation@Break 50mm/min(2 inch/min)(%) | 136 | ASTM D638 |
| Flexural Strength 1.27mm/min(2 inch/min)(kgf/cm²) | 620 | ASTM D790 |
| Flexural Strength 1.27mm/min(3 inch/min)(kgf/cm²) | 20800 | ASTM D790 |
| Low temperature falling dart impact(g) | 791 | ASTM D358 |
| Atmospheric temperature falling dart(g) | 1701 | ASTM D358 |
| Lzod Impact Strength Notched@23 ℃(J/m) | 98 | ASTM D256 |
| Rockwell Hardness(℃) | 106 | R-scale |
| Heat Distortion Temperature 0.45Mpa(66 psi)(℃) | 77 | ASTM D648 |
Application For PETG Sheet
PETG sheet is used as a midrange-priced product between Acrylic and Polycarbonate. The clarity of PETG approaches that of Acrylic and the Impact Resistance of Polycarbonate. Also is used in dental aligners, signs, POP Displays, etc.
FAQ
Q1. Are you a factory or trade company?
A: We are a professional manufacturer with 15 years experience if you have interest welcome to visit our factory.
Q2. Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free, but charge by freight collection.
Q3. How about the lead time?
A: Normal sample supply it at once. Unique samples need 3 days. mass production is generally 5-10 working days after receiving your initial payment.
Q4. Do you have any MOQ limits?
A: Normal only 1000kgs, Special colors about 5000kgs.
A: 30% T/T in advance, balance before shipment. We accept L/C at Sight.
|
