U-TE-15 Paste Thickener Equipment 15m Diameter Tailing Sedimentation Equipment

U-TE-15 Paste Thickener 15m Diameter Tailing Sedimentation Thickener Equipment

Product Description:

Center drive thickener is consist of cycle tank, rake and drive unit. The bottom of thickener is sloping cone, slope degree: 6°～12°. Normally, the tank is make by concrete, diameter is small, which can also use steel plate. Overflow chute is on the internal side of wall of tank. The vertical column in the center of tank is connected with rake device, which is consisted with rake arm, rake blade and fasten rods. Two rake rams vertical a cross. In order to discharge the settling product on the tank bottom completely, the rake blade mount on the ram with 30° sloping degree. Vertical column is on the inside hole of screw gear. Due to the location function of connecting key, the vertical column only move up and down along the screw gear shaft.

Features:

Combined with hi-efficient thickener principle and design philosophy, the unit area capacity increased, good dewatering efficiency, easy to achieve hi-efficient operation.

Center buffing and deep slurry feeding, no feeding impact

Center hydraulic drive, with automatic rake protection

Adopt central reversal cone hopper, tailings squeezed twice, density of tailings increased, more stable.

Reasonable slurry reforming structure, increase the concentration efficiency

Surrounding overflow chute design, effective settling area increased, overflow liquid is more purity.

Mult-points flocculant adding

Adopt heavy pivoting support, durability and trouble-free operation

Technical Parameters:

FAQ:

Q: What is the brand name of the thickener equipment?

A: The brand name of the thickener equipment is UNIVEE.

Q: What is the model number of the thickener equipment?

A: The model number of the thickener equipment is U-TE.

Q: Where is the thickener equipment manufactured?

A: The thickener equipment is manufactured in China.

Q: What are the applications of the UNIVEE U-TE thickener equipment?

A: The UNIVEE U-TE thickener equipment is widely used in various industries such as mining, metallurgy, chemical engineering, and environmental protection for solid-liquid separation.

Univee（Chongqing）Electrical Technology Co., Ltd (hereinafter UNVIEE) is a professional company, specialized in electromechanical equipment research and development, manufacturing, sales and installation. UNIVEE devotes to customized equipment design, manufacture and technical services in solid-liquid separation, industry sewage/waste gas treatment, mine tailings treatment and recycle, solid waste harmless treatment, municipal sewage and waste treatment.

UNIVEE has strong professional design and technical service experience. The core department of UNIVEE is consisted with Chinese specialists who are from a UK leading company, Delkor in solid-liquid separation equipment field. The technical team of UNIVEE has been continuously improved, innovated, optimized in these years by combining Delkor solid-liquid theory, Chinese technical standard and newest international standard, we formed an advantage solid-liquid theory and applied into practice, which are successfully in each kind of environmental protection, sewage/waste gas treatment and solid-liquid industries of UNIVEE’s.

We adheres “Integrity, Prosperity, Innovation” principle to cooperate with our clients and create a better green future.

Main scope of supply: Horizontal vacuum belt filter (HVBF), Ceramic vacuum filter (CVF), Hi-efficient thickener (HT), Deep cone type thickener (DCT), Vertical filter press (VFP), Squeezing filter (SF), Pressure filter (PF), Hydocyclone (HC), etc., which is widely applicated in energy source, chemical industry, mine, metallurgy, fertilizer, pharmacy, food industry, power plant (FGD), paper, textile and printing, sewage treatment, tailing treatment and municipal sewage/waste gas purification, recycle and solid-liquid separation fields.

Our company has an experienced technical developing team, with capability of specialized design, installation, aftersales support and guarantee, providing professional technical services and operation management supports. During the market developing, UNIVEE also cooperated with related research institutes and companies for technology and projects.
