Categories | Automated Guided Carts |
---|---|
Brand Name: | Remarkabl |
Model Number: | RWP/KPX/RGV/AGV |
Certification: | ISO9001,ISO14001,ISO45001,CE |
Place of Origin: | china |
MOQ: | 1 |
Payment Terms: | L/C, T/T |
Supply Ability: | 500 sets/year |
Delivery Time: | 40 days |
Packaging Details: | The whole cart will be packed by the tarp, the parts will be packed by polywood case. |
name: | Automated Guided Carts |
Power Supply: | Maintenance Free Battery /lithium Battery |
Climbing slope: | No More Than 2 Degrees /customized |
Brake: | Electric Motor Brakes |
Control Method: | Remote Control/ Hand Operate Pendant/PLC |
Warranty: | 1 Year |
Safety Features: | Audible And Visual Alarm Lamp And Emergency Stop Button,Anti-collision Edge,Laser Obstacle Avoidance Sensor |
feature: | Automated ,explosion-proof,high temperature,Omnidirectional movement/Lifting/Clamping device/customized |
Move Way: | Forward,backward,Omnidirectional movement, horizontally and diagonally movement, and can rotate 360 degrees in place ,turning while driving with no stop |
Application: | Industrial Filed,hydropower industry,military industry, automobile industry,Widely, Material or stock shuttle, Light and heavy industry, Workshop/factory etc |
Running speed: | 0-25 M/min(Adjustable) |
Key words: | transfer cart,transfer trolley,battery transfer trolley,Industrial Transfer Cart,Coil transfer transfer cart,heavy-duty transporter, trackless transfer cart, Transfer Cart, |
Steering mode: | Differential , hydraulic, steering wheel |
model: | Battery trackless transfer cart RWP/AGV |
AGV is generally powered by batteries. AGV is equipped with
non-contact navigation (guidance) devices, which can achieve
unmanned transportation operations. Its main function is to
accurately walk and park at designated locations according to path
planning and job requirements under computer monitoring, and
complete a series of job functions.
Featuring wheeled mobility, compared to walking, crawling, or other
non wheeled mobile robots, it has advantages such as fast movement,
high work efficiency, simple structure, strong controllability, and
good safety. Compared with other commonly used equipment in
material transportation, the activity area of AGV does not require
fixed devices such as tracks and support frames, and is not limited
by the site, roads, and space. Therefore, in automated logistics
systems, their automation and flexibility can be fully reflected,
achieving efficient, economical, and flexible unmanned production.
Technical parameters for trackless electric transfer carts | ||||||||
rated load(t) | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 150 |
impacted rated load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 | 225 |
structure of frame | steel plates welded, beam structure | |||||||
max. wheel load(t) | 2.8 | 4.3 | 4.8 | 5.6 | 7.7 | 10 | 12 | 27 |
ground requirement | cement floor | steel plate ground | ||||||
table size(mm) | 3000×2000 | 3600×2000 | 4000×2200 | 4500×2200 | 5000×2200 | 5500×2300 | 6000×2300 | 10000×3000 |
height of the whole cart(mm) | 450 | 530 | 600 | 600 | 650 | 700 | 700 | 1200 |
ground clearance(mm) | 50 | 75 | ||||||
wheels base(mm) | 1500 | 1700 | 1800 | 2000 | ||||
axles distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 | 10000 |
turning radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 | 10001 |
turning type | turning while driving with no stop | |||||||
control method for turning | control button | |||||||
turning structure | mechanical | |||||||
motor power(Kw) | 3.5 | 5 | 6 | 7 | 10 | 12 | 15 | 15 |
wheel diameter(mm) | Ф300 x 4 | Ф350 x 4 | Ф400 x 4 | Ф400 x 6 | Ф500 x 6 | Ф600 x 8 | ||
wheel material | ZG55+hydropur ture | |||||||
running speed(m/min) | 0-15 | 0-12 | ||||||
brake principle | electric magnetic brake | |||||||
operation method | with wire or no wire | |||||||
battery model | D-250 x 24 | D-33 x 24 | D-400 x 24 | D-440 x 24 | D-250 x 36 | D-330 x 36 | D-440 x 36 | D-600 x 36 |
battery maintenance | free of maintenance | |||||||
charger's installation | installed on cart | split-type | ||||||
charger function | automatic charging | |||||||
radar control | 3-0.3m, automatic stop for obstacles | |||||||
warning equipment | sound and light | |||||||
other functions | turning light, night light and power display |
![]() |
