P16 DIP 7000 Nits Outdoor Full Color Led Display 100000 Hours LED Life

Categories Outdoor Fixed LED Display
Brand Name: Shenzhen LED World
Model Number: LW-FO 16
Certification: CE,RoHS,FCC,CCC
Place of Origin: China
MOQ: 1 square meter
Price: negotiable
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5,000 square meters per month
Delivery Time: 10~20 days after receiving the deposit
Packaging Details: Carton/Plywood case etc.
Pixel: 1R1G1B
Configuration: DIP
Pixel Density: 3,906
Cabinet Size(mm): 1024x1024 ( Optional )
LED Life: 100,000 hours
Supply Voltage: AC220V/50HZ; AC110V/60HZ
Operating Humidity: 10% - 90%
Viewing Angle: H: 120°; V: 120°
Power: Max: 1000
Brightness: >7000cd/㎡
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

P16 DIP 7000 Nits Outdoor Full Color Led Display 100000 Hours LED Life

Outdoor series fixed led display_201905211506521.p...P16 DIP 7000 nits Outdoor Fixed LED Display / electronic sign board with IP65


Fixed LED Display / electronic sign board Quick detail:

  1. Pixel pitch: P16 outdoor ;
  2. Pixel Density: 3906 dots/sqm ;
  3. Cabinet size: Normally 1024 x 1024 mm or customized ;
  4. Cabinet material:Cold Rolled Steel ,die-casting or aluminum ;
  5. Refresh rate: 300-3000HZ adjustable;
  6. IP Rating:front IP65 .

Fixed LED Display / electronic sign board Features:

  1. DIP lamp, more stable performance, longer life, higher brightness ;
  2. This type of cabinet is also suitable for P4, P8 ;
  3. Products for CE, RoHS, FCC certification ;
  4. Support for dead pixels detection .

Parameters:

ItemsParameterP16mm
ModulesPixel1R1G1B
ConfigurationDIP
Pixel Pitch16mm
Pixel Density3,906
Module Size(mm)256x128
Pixels/Module16x8
CabinetCabinet Size(mm)1024x1024
( Optional )
Pixels/Cabinet64x64
Cabinet Weight41KG
Electricity parameterBrightness>7000cd/㎡
Viewing Distance>16m
PowerMax: 1000
Consumption(W/㎡)Ave: 200
Driver ModeStatic Latching
Viewing AngleH: 120°; V: 120°
Cabinet MaterialCold Rolled Steel
Refresh Rate300-3000HZ adjustable
LED Life100,000 hours
Supply VoltageAC220V/50HZ; AC110V/60HZ
Operating Temperature-20℃ ~ +50℃
Operating Humidity10% - 90%
Gray ScaleRed, Green and Blue each 16K
Display Color4096 Billion
IP RatingFront IP65
Display CapabilityText, Graph and Video
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Applications:

Our product used in theatres and Retail outlets;event,live meeting,pedestrian streets,big square,financial industry,public places,government agencies,Celebration,Campus,Indoor stage,Shopping area,airports, the studio center,entertainment TV,ferry,antechamber,commercial building,television studio, actories,large shopping mall, restaurants, aiming at the exhibition,industrial park,outside parking lots,Entertainment complexes,monitoring centers,lottery center,beauty shop...


Our company:

Shenzhen LED World co.,ltd specialized in the development and manufacture of LED display system products.Founded in 2007, with the registered capital 30 millionRMB, owns workshop area 9,000 m2. Branched offices and agents all over China, with about 400 employees.
since its establishment, we are always following the new changes of LED industry. So far, our LED products are sold widely around the world.
Shenzhen LED World Optoelectronics Limited is the top professional LED Display manufacturer, and has about 9 years experience in LED screen industry, more than 9000sqm workshop, 400 workers, automatic production line, strong R&D team. Our products have passed RoHS, 3C, FCC and CE quality authentication.
