14 Bit 6mm Outside Led Video Wall Screen Permanent With Nova Linsn Control System

Categories Outdoor Fixed LED Display
Brand Name: Shenzhen LED World
Model Number: LW-FO 6
Certification: CE,RoHS,FCC
Place of Origin: China
MOQ: 1 square meter
Price: Negotiation
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 3,000 square meters per month
Delivery Time: 12-20 working days after received your payment
Packaging Details: Carton/Plywood case etc.
Module size: 192mm×96mm
Colors: 16777216
Brightness: ≥6000cd/m2
Gray scale: 16bits of per color
MTBF: More than 10,000 hours
Vertical viewing angle: 120°
Usage: Outdoor
Screen dimension: Customized Size
Tube chip color: Full Color
Refresh rate: 1920/3840
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

14 Bit 6mm Outside Led Video Wall Screen Permanent With Nova Linsn Control System

14 Bit 6mm Outside Led Video Wall Screen permanent With Nova Linsn Control System​


Features:

  • High brightness, more than 6500 nits;
  • Kinglight LED lamp and Macroblock 5124 made;
  • Cabinet weight is only 9.3 kg, depth 73 mm, decreasing the transportation cost and the intensity of labor.
  • Super thin power supply inside; Quiet fan design, excellent heat dissipation, noiseless;
  • Durable lamp, working hour more than 100,000 hours;
  • San’an LED lamp and Macroblock 5124 IC made;
  • Low cost for maintenance by only replacing the malfunctioned piece;

Application:

Wide applied in show,large events,government project,chain shop,conference,HR market,tennis,commercial applications,insurance company,fitness hall,mansion video wall,bank,touring and so on .


​Parameter:

NumbersTechnical indexesSpecification
1Pixel pitch6mm
2Module size192mm×96mm
3Module resolution32×16
4Module density27,777dots/sqm
5Pixel configurationFull color
6Red wavelength625±2nm
7Green wavelength525±2nm
8Blue wavelength470±2nm
9Colors16777216
10Best viewing distancemore than 5m
11Horizontal viewing angle140°
12Vertical viewing angle120°
13Maximum power consumption≤500W/2
14Brightness≥6000cd/m2
15Gray scale16bits of per color
16Color temperature6500K
17Control methodSynchronization or Asynchronization
18Driving method1/8scanning
19Frame frequency480Hz
20Refresh frequency≥2000 Hz
21Working voltageAC220V/110V±10%
22IP gradeIP53
23Working temperature-20°C~80°C
24MTBFMore than 10,000 hours
25life spanmore than 100,000 hours
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Our service:

  • Quality test report for every order;
  • Data sheet and samples offer;
  • We also could solve problems for you until it recovers well by remote control;
  • Other services, such as special packing design, factory visiting and so on;
  • Special discount and protection of sales area provided to our distributor;
  • Tracking report in producing;
  • We can send our engineer on site to guide the installation for you. The relevant costs should be paid by your esteemed company, such as visa, hotel, food, plane ticket back and so on;
  • We provide technology training for free, which contains the operation and maintenance training of the LED screens in factory;
